Brand Name: IMAKO
Price: Negotiable
Model Number: TP-35C
Power: 10KW
Application: N/Z Fold Hand Towel Paper and Napkins
Weight: 3600KG
Output: 35Pack/Min
Packaging dimension: Length (L): 150~300 Width (W): 110~250 Height (H): 70~115 mm
Place of Origin: CHINA.
Certification: CE, ISO
Minimum Order Quantity: 1 SET
Trading Method: FOB/CIF/EXW Xiamen Port
Delivery Time: 90 Days
Packaging logistics: In wooded cases with fumigation finish or wrapped with plastic film.
★Using prefabricated cylinder roll film, thermos transfer printer, ink wheel coding machine and ribbon coding machine can be pre-installed.
|
TP-35C main parameter configuration |
|||
|
Scope of application |
N fold hand towel |
Roll film correction |
Automatic correction |
|
Feeding mode |
Automatic feeding |
Machine weight(KG) |
3600 |
|
Packaging material install structure |
Air shaft |
Packing film type |
Prefabricated bag roll film |
|
Film roll diameter(mm) |
≤600 |
Power supply |
380V/50Hz |
|
Machine size(mm) |
L3000*W1800*H1850 |
Compressed Air (mpa) |
Air source≥0.5, Air flow≥300L / min |
|
Bag cutting mode |
Insert cutting |
Total power(KW) |
10 |
|
Pronghorn molding |
forming mould |
Options |
Printer,perforation device |
The paper towel arrangement, feeding, filling, pulling, conveying and sealing are controlled by servo motors. It is simple to operate and convenient for maintenance.
Adopts servos control for tissue arrangement, counting, stacking, tissue fill to bag, bag catching, bag conveying, bag opening and seal parts, This machine is easy to operation and main...
The paper towel arrangement, counting, feeding, filling, pulling and other action unit are servo drive control. It is simple to operate and convenient for maintenance....
1.Adopts servos control for tissue arrangement, counting, direction changing, tissue fill to bag, bag catching, bag conveying, bag opening and seal parts, This machine is easy to operat...
The machine combine the high qualification rate and effective productivity to one, save labor and raw material cost. Control system is completely self-contained, run stably....
